RaVolt 800
Compact, reliable, and ready when you need it.
- 800W Pure Sine Wave AC Output
- 512Wh Long-Life LiFePO4 Battery
- Ultra-Fast AC Charging
- Solar Charging Ready
- Multiple Output Ports
Key Specifications
Need a custom quote?
Email us with the product, quantity, and installation details and we'll prepare a competitive proposal.
Product Details
Product Specifications
RaVolt 800 combines a 512Wh LiFePO4 battery, 800W pure sine wave inverter, smart charging, and wide device compatibility into a compact portable power station built for home backup, travel, and outdoor use.
Key Features
800W Pure Sine Wave AC Output
Provides 800W continuous output with 1600W surge power, making it suitable for laptops, TVs, CPAP machines, mini-fridges, routers, power tools, drones, cameras, and other essential appliances.
Long-Life LiFePO4 Battery
Built with premium LiFePO4 battery cells offering:
- 512Wh capacity
- Over 4,000 charge cycles
- 80% capacity retention after 4,000 cycles
- Improved safety and thermal stability
- Long service life
Ultra-Fast AC Charging
Recharge the battery quickly through a wall outlet with:
- Maximum AC charging power: 550W
- Approximately 1.2-hour full recharge
- High charging efficiency up to 95%
Solar Charging Ready
Recharge using compatible solar panels for off-grid applications.
- Solar input: Up to 300W
- MPPT charging
- DC input voltage: 12-60V
- Maximum input current: 10A
Vehicle Charging
Recharge while travelling.
- Car charging input: 120W
- Compatible with 12V vehicle charging
SmartDrive Technology
Automatically manages overload conditions, allowing the inverter to safely power compatible devices beyond its rated output without sudden shutdowns.
Pure Sine Wave Inverter
Produces clean and stable AC power with THD below 1.5%, making it safe for sensitive electronics including computers, networking equipment, medical devices and audio/video equipment.
Advanced Battery Management System (BMS)
Intelligent protection system safeguards both the battery and connected devices through multiple protection mechanisms.
Multiple Output Ports
Power up to 10 devices simultaneously through:
- AC outlets
- USB-C PD ports
- USB-A fast charging ports
- 12V car socket
- Dual DC5525 outputs
Portable Design
Compact, lightweight construction with integrated carry handle, making it ideal for:
- Camping
- Caravan/RV travel
- Fishing
- Outdoor events
- Emergency preparedness
- Mobile offices
Built-in LED Light
Integrated 3W LED light for emergency lighting and outdoor use.
Wireless Connectivity
Supports Wi-Fi and Bluetooth for app-based monitoring and control.
Technical Specifications
Battery
| Battery Type | LiFePO4 |
|---|---|
| Battery Capacity | 512Wh |
| Nominal Battery Voltage | 25.6V |
| Battery Voltage Range | 40-60V |
| Nominal Charging Current | 20A |
| Nominal Discharging Current | 40A |
| Maximum Discharging Current | 50A |
| Battery Life | 4,000+ cycles (80% DOD @25°C) |
AC Input
| AC Charging Power | 550W |
|---|---|
| Input Voltage (100V Model) | 100VAC |
| Input Voltage (230V Model) | 230VAC |
| Voltage Range (100V) | 85-130V |
| Voltage Range (230V) | 180-260V |
| Frequency (100V) | 60Hz |
| Frequency (230V) | 50Hz |
| Frequency Range (100V) | 55-65Hz |
| Frequency Range (230V) | 45-55Hz |
| Power Factor | >0.99 |
DC / Solar Input
| Maximum Car Charging Input | 120W |
|---|---|
| Maximum Solar Charging Input | 300W |
| DC Input Voltage | 12-60V |
| Maximum PV/DC Input Current | 10A |
AC Output
| Rated Output Power | 800W |
|---|---|
| Peak Surge Power | 1600W |
| Output Voltage | 100VAC / 230VAC |
| Output Frequency | 50Hz / 60Hz |
| Rated Output Current | 8A (100V) / 3.5A (230V) |
| Waveform | Pure Sine Wave |
| THD | <1.5% |
USB & DC Outputs
| USB-C1 | 100W PD (5V, 9V, 12V, 15V, 20V) |
|---|---|
| USB-C2 | 30W PD |
| USB-C3 | 30W PD |
| USB-A1 | 30W Fast Charge |
| USB-A2 | 30W Fast Charge |
| Car Socket | 13.2V, 10A (132W Max) |
| DC5525 Outputs (2x) | 13.2V, 10A each |
| Maximum Combined DC Output | 132W |
Efficiency
| Battery - AC Efficiency | Up to 95% |
|---|---|
| AC - Battery Charging Efficiency | Up to 95% |
Protection Features
- AC output over-current
- Short circuit
- Over-voltage
- Under-voltage
- Over-frequency
- Under-frequency
- Inverter over-temperature
- AC charging over-current
- AC charging over/under-voltage
- Battery over-voltage
- Battery under-voltage
- Battery high temperature
- Battery low temperature
General Specifications
| Dimensions | 299 x 191.4 x 196.6 mm |
|---|---|
| Weight | 6.5 kg |
| Cooling | Forced Air Cooling |
| Charging Temperature | 0°C to 40°C |
| Discharging Temperature | -15°C to 40°C |
| Operating Humidity | 0-95% RH (Non-condensing) |
| Ingress Protection | IP20 |
| Noise Level | <60 dB |
| Wireless Connectivity | Wi-Fi & Bluetooth |
| LED Light | 3W |
Ideal Applications
- Home emergency backup
- Camping & outdoor adventures
- Caravan and RV travel
- Off-grid living
- Photography and drone charging
- Mobile workstations
- Fishing trips
- Construction sites
- Events and exhibitions
- Powering medical devices such as CPAP machines
- Backup power for routers and communication equipment
